One Track

3 Circuit Data Track

A 3-circuit track lighting system (-EU configuration only) offers unparalleled flexibility with independent control over three lighting circuits on one sleek, durable aluminum track for seamless lighting customization in any space.

Separator

Custom Lengths

Track segments can be cut on location

Mounting Points

Pre-drilled slots for easy mounting

DMX Ready

Supports up to 30 devices

Separator

Specifications

Track Type	Surface Mounted Track (commercial grade)
Conductors(-TOX)	7 (2 Data, 2 Live, 2 Neutral, 1 Ground)
Conductors(-TON)	5 (2 Live, 2 Neutral, 1 Ground)
Input Voltage	220V
Circuits	3 (16A max per circuit, 48A max per track)
Material	Aluminum / PVC / Polycarbonate / Copper conductors
Number of DMX Fixtures	30 Max
Max Load	50kg / 110lbs (per 1.5’ of track)
Color Options	Black / White
Segment Length Options	3.2ft (1000mm) / 6.5ft (2000mm)
Track Mounting Points	0.47” x 0.16” (11mm x 4mm) Slot Per 1.64’ (500mm)

Separator

Polarity Ridge

There a mechanical key on the track to guarantee the proper connection of multiple pieces of track. This key is present on all end-feeds and connecting components (see screw below-pictured). Care must be taken when ordering to select the correct components.
